The Clean Burn Model CTB-350 waste oil boiler has an input rating of 350,000 BTU/hr and an output rating of 260,00 BTU/hr. The CTB-350 is UL listed for use in central heating systems.
With the mid-sized CTB-350, you spend 30 minutes cleaning every 1000 hours of operation. It is uniquely designed for installation flexibility. Engineered for use as a single boiler unit, or it can be used in combination with any Clean Burn boiler to create a system perfectly sized for any facility.
|BTU/hour input:||350,000 (102 kW)|
|BTU/hour output:||260,000 (76.2 kW)|
|Fuels||Used oils: Crankcase,ATF, hydraulic|
Fuel oils: #2, #4, and #5 fuel oil
|Heating Surface||68 sq. ft. / 6.3 sqM|
|Boiler water volume||12 gal. / 45.4 L|
|Design water flow per coil||12 gal. / 45.4 L|
|Cabinet dimensions||56″ L x 34″ W x 34.5″ H|
142cm x 86cm x 88cm
|74″ L x 39.25″ W x 41″ H|
188cm x 100cm x 104cm
|Approx. Weight||1240 lbs. / 562.4 kg|
|Electrical Requirements||115 VAC 60 Hz single phase*|
*230V/ 50Hz units also available
|Maximum oil consumption||2.5 GPH / 9.5 lph|
|Stack size||8″ / 20cm|
|Air compressor required||2.5 CFM @ 25 PSI|
4.25 m3/h @ 1.7 bar
|Recommended clean-out||1000 hours|
*Values indicated above are nominal. Actual values will vary depending on fuel and installation.
